K6237 DLRO KEPLER Digital Low Resistance Ohm Meter

Details of KEPLER  Digital Milliohm Meter (Low Resistance Ohm Meters) K6237 DLRO

• Uses a microprocessor for control
• Makes measurements as low as 1µΩ
• Has six measurement ranges: 2.000mΩ~200.0Ω
• Employs four-terminal measurement method, ensuring high accuracy
• Large and clear LCD display
• Data Hold feature to retain measured values
• Automatic power-off when not in use
• Battery-powered with rechargeable battery
• Durable and compact design
• Status indicator lights warn of potential reading inaccuracies (RP, RC, and temperature)

Technical Data KEPLER  Digital Milliohm Meter (Low Resistance Ohm Meters) K6237 DLRO

• Low resistance ranges / resolution :
  • 0~2.000mΩ / 1µΩ ±(5%rdg+dgt) : 0~2.000Ω / 1mΩ ±(3%rdg+4dgt)
  • 0~20.00mΩ / 10µΩ ±(4%rdg+4dgt) : 0~20.00Ω / 10mΩ ±(2%rdg+4dgt)
  • 0~200.0mΩ / 100µΩ ±(4%rdg+4dgt) : 0~200.0Ω / 100mΩ ±(2%rdg+4dgt)
• Test current (DC) : 2.000mΩ~200.0mΩ : 1A ±3% / 200.0mΩ~20.0Ω : 100mA ±2% / 200.0Ω : 10mA ±1.5%
• Maximum output voltage (C1~C2) : 10V
• Dimensions : 330(L) x 260(W) x 160(D)mm
• Weight (battery included) : Approx. 3200g
• Power source : Rechargeable battery
• Safety standard : EN 61010-1, EN 61326-1
