KYORITSU Analog Insulation Tester Model 3166

The KYORITSU model 3166 Analog Insulation Tester is a compact and lightweight device, making it easy to carry. The test voltage range supports measurements at 1000V / 2000MΩ.

• Test Voltage Range 1000V / 2000MΩ
• The insulation resistance scale is enlarged, making it easier to read values.
• The meter structure is new and exceptionally sturdy.
• AC voltage range readings are easy to read.

Technical Data KYORITSU Analog Insulation Tester Model 3166

• DC Test Voltage 1000V
• Max. effective scale value 2000MΩ
• Mid-scale value 50MΩ
• First effective measuring range 2~1000MΩ
• Accuracy ±5% rdg
• Second effective measuring ranges 1 / 2000MΩ
• Accuracy ±10% rdg
• AC voltage range 600V
• Accuracy ±3% of full scale value
• Power source R6 (AA) (1.5V) x 4
• Dimensions / Weight 90(L) x 137(W) x 40(D)mm / 330g approx
• Included Accessories 7025 (Test leads) 9067 (Pouch for test lead) Neck Strap R6 (AA) x 4 Instruction Manual
