IIC221 \ efector 100 \ Inductive sensor \ IIK2022-ASI /M/US-104 \ DE

Details of IIC221 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2022-ASI /M/US-104 \ DE

IIC221 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2022-ASI /M/US-104 \ DE Inductive sensor/ Proximity switch/ Proximity sensor (Proximity switch/ Proximity sensors/ Inductive sensors) with M30 x 1.5 cylinder, sensing distance of 22 mm from ifm for detecting metal objects in industrial manufacturing processes. Compact size allows installation in limited spaces and comes with dust and water protection standards to withstand all weather conditions.

Features of IIC221 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2022-ASI /M/US-104 \ DE

• Electrical design AS-i
• Operating voltage [V] 26.5...31.6 DC (AS-i)
• Current consumption [mA] < 30
• Protection class III
• Reverse polarity protection yes
• Correction factors mild steel = 1 / stainless steel approx. 0.7 / brass approx. 0.5 / aluminium approx. 0.45 / copper approx. 0.35
• Hysteresis [% of Sr] 1...20
• Switch-point drift [% of Sr] -10...10
• Power-on delay time [ms] < 1000
• Ambient temperature [°C] -25...70
• Protection IP 68; "Coolant"
• Mounting non-flush mountable
• Housing materials stainless steel (316L); active face: LCP uncoloured
• Weight [kg] 0.115
