IIC220 \ efector 100 \ Inductive sensor \ IIK2014BASI /M/US-104 \ DE

Details of IIC220 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2014BASI /M/US-104 \ DE

IIC220 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2014BASI /M/US-104 \ DE Inductive sensor/ Proximity switch/ Proximity sensor (Proximity switch/ Proximity sensors/ Inductive sensors) from ifm for detecting metal objects in industrial manufacturing processes. Compact size, easy to install in limited spaces, and equipped with dust and water protection standards to withstand all weather conditions.

Features of IIC220 \ efector 100 \ Inductive sensor (Metal detection sensor for AS-interface system) \IIK2014BASI /M/US-104 \ DE

• Electrical design AS-i
• Operating voltage [V] 26.5...31.6 DC (AS-i)
• Current consumption [mA] < 30
• Protection class III
• Reverse polarity protection yes
• Sensing range [mm] 14
• Operating distance [mm] 0...11.34
• Correction factors mild steel = 1 / stainless steel approx. 0.7 / brass approx. 0.5 / aluminium approx. 0.45 / copper approx. 0.35
• Hysteresis [% of Sr] 1...20
• Power-on delay time [ms] < 1000
• Ambient temperature [°C] -25...70
• Protection IP 68; "Coolant"
• AS-i version 2.1
• Extended addressing mode possible yes
• AS-i profile S-0.A.F
• I/O configuration [hex] 0
• ID code [Hex] A.F
• AS-i certificate 57401
• Mounting flush mountable
• Housing materials stainless steel (316L); active face: LCP uncoloured
• Weight [kg] 0.121
