GW INSTEK GDS-1102B Digital Storage Oscilloscope

Details of GW INSTEK Oscilloscope (Digital Storage Oscilloscope) Model GDS-1102B Digital Storage Oscilloscopes

• Frequency options for use: 50, 70, 100MHz, 2 or 4 channel types
• Vertical Sensitivity Resolution : 8bit 1mV~10V/div
• Time Base : 5ns/div~100s/div
• 7-inch TFT Color LCD WVGA screen with a resolution of 800x480 pixels
• Waveform Update Rate at 50,000 wfms/S
• Real Time Signal Sampling Rate up to 1 GSa/s. Max. Memory Depth for Each Channel is 10M
• Number of points in FFT Frequency Domain display up to 1,000,000 points
• Able to show waveform zoom window (Zoom Window)
• Able to perform waveform playback in PLAY/PAUSE mode
• Save and Recall Setup values for 20 setups, 24 waveforms
• Functionality for automatic measurement of waveform signals
• Supports mathematical functions +, -, X, ÷, FFT, FFTrms, User Defined Expression

Tech Specifications GW INSTEK Oscilloscope (Digital Storage Oscilloscope) Model GDS-1102B Digital Storage Oscilloscopes

• Channels : 2ch+Ext.
• Real Time Sample Rate : 1Gsa/s max.
• Bandwidth : 100MHz
