GW INSTEK GDS-1074B Digital Storage Oscilloscope
Special Price THB 37,200.00 Regular Price THB 46,500.00
Out of stock
SKU
027873
Out of stock
Delivery date: 4 ก.ย. 2569
Oscilloscopes (oscilloscopes), oscilloscope price, digital scope, which brand is good, scope meter, portable scope, signal measurement, Oscilloscopes, gw instek
*Price does not include VAT
Details of GW INSTEK Oscilloscope (Digital Storage Oscilloscope) Model GDS-1074B Digital Storage Oscilloscopes
- Frequency options: 50, 70, 100MHz, 2 or 4 channel models available
- Vertical Sensitivity Resolution : 8bit 1mV~10V/div
- Time Base : 5ns/div~100s/div
- 7-inch TFT Color LCD WVGA screen with a resolution of 800x480 pixels
- Waveform Update Rate at 50,000 wfms/S
- Real Time Sampling Rate up to 1 GSa/s. Maximum Memory Depth for Each Channel is 10M
- FFT Frequency Domain Signal Display Points Up To 1,000,000 points
- Waveform Zoom Window Available
- Waveform Play/Pause Functionality Supported
- Able to Automatically Measure and Display up to 36 signal parameters
- Save and Recall Setup Values: 20 setups, Waveforms: 24 waveforms
- Automatic Signal Measurement Function Available
- Supports Mathematical Functions +, -, X, ÷, FFT, FFTrms, User Defined Expression
Tech Specifications of GW INSTEK Oscilloscope (Digital Storage Oscilloscope) Model GDS-1074B Digital Storage Oscilloscopes
- Channels : 4ch
- Real Time Sample Rate : 1Gsa/s max.
- Bandwidth : 70MHz
| จำนวนวันจัดส่ง | 3 วัน |
|---|---|
| Special Price | THB 37,200.00 |
