R1D103 \ efector 240 \ Radar sensors \ R1DADOOKG/US/CAN \ RO

DUALEM-21/21S Details

The DUALEM-21/21S features a Dual-Geometry receiver array at distances of 2 meters and 1 meter from the transmitter, allowing simultaneous conductivity measurements at four depth levels: 0.5 meters, 1 meter, 1.6 meters, and 3.2 meters. Additionally, it can measure magnetic susceptibility (Magnetic Susceptibility) simultaneously in four values and detect metal.

DUALEM-21/21S Usage

• The ability to measure at multiple depth levels enables analysis of the first 4 meters of soil depth.
• It can be used for long-range surveys by a single operator.
• Suitable for towing on a sled or low cart.

*SCMA is the sole distributor in Thailand.

DUALEM-21/21S Features

• EM Arrays 1- and 2-m horizontal co-planar (HCP) and perpendicular (PRP) transmitter-receiver arrays, operating at 9 kHz
• Measured EM Quantities HCP apparent conductivity and in-phase
• PRP apparent conductivity and in-phase
• Measuring Ranges Conductivity: -1000 to +1000 mS/m, 0.1 mS/m resolution
• In-phase: -300 to +300 ppt, 0.01 ppt resolution
• Data Rates 1 Hz standard, optional rates include 0.1-, 5- and 10-Hz
• Integrated Components Digital signal processor, GPS receiver, indicator LEDs, RS-232 port, thermometers, Wi-Fi transceiver
• Power 8- to 16-V DC from harness module or external battery, draw about 3 W
• Operating Dimensions 0.089-m diameter, 2.41-m length (3.5” by 95”)
• Weights 8 kg operating, 24 kg shipping
• Shipping Dimensions 2.55m x 0.18m x 0.18 m
• Ancillary Items Data/power cable, software and documentation, hinged metal case. DUALEM-21 has a Bluetooth transceiver, controller and harness
