DI6005 \ ecomat 200 \ Evaluation systems and power supplies\ DGA4007-WRKG/IO/US

Details DI6005 \ ecomat 200 \ Evaluation systems and power supplies\ DGA4007-WRKG/IO/US

DI6005 \ ecomat 200 \ Evaluation systems and power supplies\ DGA4007-WRKG/IO/US IO-Link rotary speed sensor designed compactly for installation in limited spaces

• Able to read multiple values through the IO-Link switch, also offers pulse output options
• Reliable non-contact rotational speed monitoring
• 2-in-1 : integrated speed and evaluation in a small compact housing
• Durable metal housing that eliminates the need for additional protective housings against impact
• Easy to set up via teach button IO-Link
• Simplifies installation complexity
• IO-Link for signal transmission and diagnostic data
• Flush mountable and non-flush versions available
• Versions certified for explosion protection (ATEX)

Tech Data DI6005 \ ecomat 200 \ Evaluation systems and power supplies\ DGA4007-WRKG/IO/US

• Electrical design : PNP/NPN
• Output function : normally open / normally closed
• Sensing range[mm] : 7
• Communication interface : IO-Link
• Housing : threaded type
• Dimensions[mm] : M18 x 1 / L = 75
• Operating voltage[V] : 10...30 DC
• Output signal : switching signal
• Output signal pulse : signal; switching signal
• Switching frequency DC[Hz] : < 500
• Measuring range[Imp/min] : 1...32000
• Ambient temperature[°C] : -25...85
• Protection : IP 65; IP 66; IP 67; IP 68; IP 69K
• Mounting : flush mountable
• Connection : Connector M12
