SCR-2ATZ230 Three phases, 2W, 200-480VAC, 230A, Multi-input, Phases Zero Crossing

Details of SCR-2ATZ230 Three phases, 2W, 200-480VAC, Current 230A, Multi-input, Phases Zero Crossing

SCR-2ATZ230 Three phases, 2W, 200-480VAC, Current 230A, Multi-input, Phases Zero Crossing SCR (Silicon Controlled Rectifier) is a type of semiconductor device used to control electrical power, particularly for adjusting voltage in three-phase (Three Phase) systems. A three-phase two-wire (2W) SCR operates in systems without a neutral wire (only L1, L2, L3).

Working Principle

Voltage Control with SCR: The SCR opens and closes according to the sine wave cycle of alternating current to control the amount of power delivered to the load. This control is achieved by delaying the time (Delay) at which the SCR turns on in each sine wave cycle, or through Zero Crossing.

• Zero Crossing Triggering: A method of turning on the SCR when the AC voltage changes direction through zero volts (zero volt), reducing EMI (electrical interference) and inrush current. Suitable for resistive loads such as heaters, ovens.
• Multi-input: The input can support multiple types, such as DC 4–20mA, 0–10V, ON-OFF or digital signal, making it versatile to work with control systems like PLCs, temperature controllers, sensors.

Key Features

• Three-phase two-wire system (no neutral)
• Operating voltage 200–480VAC
• Type of phase angle or Zero Crossing control
• Mult-input control: 4–20mA, 0–10V, ON-OFF
• Overvoltage, Overcurrent, Short Circuit protection (some models)
• DIN Rail or Panel mount installation
• Applications include controlling heating loads, motors, ovens, industrial furnaces.

Applications

• Heater Control: Used to control temperature in ovens, industrial furnaces, extruders.
• Motor Soft Start (some models)
• Voltage control at startup to prevent inrush current.
• Induction furnace/systems.
• To control power in systems requiring high accuracy.
• Automatic control system with PLC/SCADA: Connects flexibly with control systems through multi-input.

Advantages of the Three-phase Two-wire SCR System

• High precision control capability
• Durable, suitable for industrial use in factories.
• Able to handle large electrical loads.
• Lowers issues with inrush current and EMI when using Zero Crossing.

Tech Data SCR-2ATZ230 Three phases, 2W, 200-480VAC, Current 230A, Multi-input, Phases Zero Crossing
