KEPLER Temperature Transmitter Model KTH-301WA

Details of KEPLER Temperature Transmitter Model KTH-301WA

The KEPLER Temperature Transmitter model KTH-301WA comes with a measurement range for both temperature and humidity, providing an accuracy of ±0.3°C/±2%RH along with a response time of 15 seconds (90% at +25°C in moving air over 0.5 MS).

• Temperature sensor RTD Pt 100 ohm with a temperature measurement range of 0°C...+100°C
• Humidity sensor Thin-film capacitor with a humidity measurement range of 0...+100%RH

The KEPLER Temperature Transmitter model KTH-301WA has a 4-20mA output for sending to display devices (Indicator) and can be calibrated at two points (Zero and Span) at the installation site. The installation type is Separate Probe Type (separate probe, cable length of 1 m).

The unit itself is made from IP65 water-resistant ABS material and supports temperatures ranging from -40°C...+85°C with a weight as light as 150g.

Technical Data of KEPLER Temperature Transmitter Model KTH-301WA

Measurement Range

• 0 ~ 100% RH, 0~100°C (-20 ~ +80°C,0~50°C,-40~+60°C available)
• Accuracy (At 25 °C) ±2% RH, ±0.3°C (Power supply = 24VDC)
• Long-term stability Better than 1% RH per year (Typical)
• Temp.Compensation ±0.008% RH/ °C(Effect 0% RH)
• Response <15 seconds (90 % at +25°C in moving air over 0.5 M/S)

Sensors

• Humidity : Thin-film capacitor
• Temperature : RTD Pt 100 IEC 751, DIN43760
• Current output : Humidity : 4 ~ 20 mA Two wire

Output

• Voltage output : 0 to 1V, 0 to 5V, 0 to 10V or 1 to 5V, Selectable
• Fine adjustment Zero and Span adjustable by spare potentiometer
• Power Supply 12 ~ 40V DC, >150 mA
• Housing / Protection ABS plastic watertight enclosure (IP 65)
• Cable gland Liquid-tight nylon, cable Bushing Ø5-10mm
• Ambient Temperature -40〜+85°C (-40〜+185°F)
• Weight Approx. 150g
• Approvals IP65;CE;RoHS
