K1155 TMF KEPLER Digital Insulation Testers

Features of KEPLER Digital Insulation Testers Model K1155 TMF

• Microprocessor controlled
• Insulation test voltage 50V, 100V, 125V, 250V, 500V, 1000V
• High insulation measurement range up to 8GΩ
• Diagnose insulation with PI and DAR functions
• Automatic switching of AC/DC voltage measurement mode
• Automatic range change
• Has an automatic discharge system after testing
• Has an Auto-Null button

Tech Data KEPLER Digital Insulation Testers Model K1155 TMF

• Test Voltage : 50V / 100V / 125V / 250V / 500V / 1000V
• Measuring Ranges : 0.1M∼400MΩ / 0.1M∼800MΩ / 0.1M∼1GΩ / 0.2M∼2GΩ / 0.2M∼4GΩ / 0.2M∼8GΩ
• Accuracy : 0.1MΩ∼4GΩ : ±3%rdg / 4GΩ∼8GΩ : ±5%rdg
• Range : 0.01Ω∼1999Ω
• AC V : 0∼700V
• DC V : 0∼950V
• Auto-Off : Approx. 5 minutes
• Operating temperature : 0°C to 40°C
• Dimensions : 175(L) x 85(W) x 75(D)mm
• Weight (battery included) : Approx. 655g
• Power Source : Alkaline 1.5V (AA) x 8
• Safety Standard : EN 61010-1 CAT III 600V, EN 61326-1
